Open Junction Wafer & Chip
With monocrystalline silicon as the carrier, various kinds of products such as STD, FR, HER, SF, TVS and so on are produced by the diffusion mode of phosphorus or boron.
Diffusion, from a microscopic point of view, is the phenomenon that molecules or atoms move from a region of high concentration to a low concentration region.
The company controls the type, concentration, depth and PN junction of the impurity in the specific area of the semiconductor through the way of high temperature diffusion, so as to get the products with different characteristics that customers need, including all kinds of products, such as STD, FR, HER, SF, TVS and so on.
- File name
- File download
- Open Junction Wafer & Chip parameter configuration table
-
- Standard Rectifier Chip parameter configuration table
-
- Fast Recovery Rectifier Chip parameter configuration table
-
- High Efficieny Rectifier Chip parameter configuration table
-
- Super Fast Rectifier Chip parameter configuration table
-
- Ultra Fast Rectifier Chip parameter configuration table
-
Standard Rectifier Chip
|
Number |
Model |
Size |
Electrical Parameters |
||||||
|
A(mil) |
B(mil) |
C(um) |
VF(V) |
IF(A) |
VR(V) |
IR(uA) |
TRR(ns)@ |
||
|
1 |
39*39 |
39+1/-3 |
39+1/-3 |
260±20 |
<0.96 |
1A |
>1000 |
1 |
>800 |
|
2 |
40*40 |
40+1/-3 |
40+1/-3 |
260±20 |
<0.96 |
1A |
>1000 |
1 |
>800 |
|
3 |
42*42 |
42+1/-3 |
42+1/-3 |
260±20 |
<0.96 |
1A |
>1000 |
1 |
>1000 |
|
4 |
44*44 |
44+1/-3 |
44+1/-3 |
260±20 |
<0.96 |
1A |
>1000 |
1 |
>1000 |
|
5 |
46*46 |
46+1/-3 |
46+1/-3 |
260±20 |
<0.96 |
1A |
>1000 |
1 |
>1000 |
|
6 |
47*47 |
47+1/-3 |
47+1/-3 |
260±20 |
<0.96 |
1A |
>1000 |
1 |
>1000 |
|
7 |
52*52 |
52+1/-3 |
52+1/-3 |
260±20 |
<0.96 |
2A |
>1000 |
2 |
>1000 |
|
8 |
55*55 |
55+1/-3 |
55+1/-3 |
260±20 |
<0.96 |
2A |
>1000 |
2 |
>1000 |
|
9 |
58*58 |
58+1/-3 |
58+1/-3 |
260±20 |
<0.96 |
2A |
>1000 |
2 |
>1000 |
|
10 |
80*80 |
80+1/-3 |
80+1/-3 |
260±20 |
<0.96 |
3A |
>1000 |
3 |
>1000 |
|
11 |
90*90 |
90+1/-3 |
90+1/-3 |
260±20 |
<0.96 |
3A |
>1000 |
3 |
>1000 |
|
12 |
110*110 |
110+1/-3 |
110+1/-3 |
260±20 |
<0.96 |
3A |
>1000 |
3 |
>1000 |
|
13 |
132*132 |
132+1/-3 |
132+1/-3 |
260±20 |
<0.96 |
8A |
>1000 |
10 |
>1000 |
|
14 |
164*164 |
164+1/-3 |
164+1/-3 |
260±20 |
<0.96 |
10A |
>1000 |
10 |
>1000 |
|
15 |
180*180 |
180+1/-3 |
180+1/-3 |
260±20 |
<0.96 |
15A |
>1000 |
10 |
>1000 |
Fast Recovery Rectifier Chip
|
Number |
Model |
Size |
Electrical Parameters |
||||||
|
A(mil) |
B(mil) |
C(um) |
VF(V) |
IF(A) |
VR(V) |
IR(uA) |
TRR(ns)@ |
||
|
1 |
FR105 |
40+1/-3 |
40+1/-3 |
230±20 |
<1.15 |
1A |
>600 |
1 |
<140 |
|
42+1/-3 |
42+1/-3 |
230±20 |
<1.15 |
1A |
>600 |
1 |
<140 |
||
|
44+1/-3 |
44+1/-3 |
230±20 |
<1.15 |
1A |
>600 |
1 |
<140 |
||
|
2 |
FR205 |
52+1/-3 |
52+1/-3 |
230±20 |
<1.15 |
2A |
>600 |
2 |
<140 |
|
55+1/-3 |
55+1/-3 |
230±20 |
<1.15 |
2A |
>600 |
2 |
<140 |
||
|
58+1/-3 |
58+1/-3 |
230±20 |
<1.15 |
2A |
>600 |
2 |
<140 |
||
|
3 |
FR305 |
80+1/-3 |
80+1/-3 |
230±20 |
<1.15 |
3A |
>600 |
3 |
<140 |
|
90+1/-3 |
90+1/-3 |
230±20 |
<1.15 |
3A |
>600 |
3 |
<140 |
||
|
4 |
FR106 |
40+1/-3 |
40+1/-3 |
230±20 |
<1.2 |
1A |
>800 |
1 |
<140 |
|
42+1/-3 |
42+1/-3 |
230±20 |
<1.2 |
1A |
>800 |
1 |
<140 |
||
|
44+1/-3 |
44+1/-3 |
230±20 |
<1.2 |
1A |
>800 |
1 |
<140 |
||
|
5 |
FR206 |
52+1/-3 |
52+1/-3 |
230±20 |
<1.2 |
2A |
>800 |
2 |
<140 |
|
55+1/-3 |
55+1/-3 |
230±20 |
<1.2 |
2A |
>800 |
2 |
<140 |
||
|
58+1/-3 |
58+1/-3 |
230±20 |
<1.2 |
2A |
>800 |
2 |
<140 |
||
|
6 |
FR306 |
80+1/-3 |
80+1/-3 |
230±20 |
<1.2 |
3A |
>800 |
3 |
<140 |
|
90+1/-3 |
90+1/-3 |
230±20 |
<1.2 |
3A |
>800 |
3 |
<140 |
||
|
7 |
FR107 |
40+1/-3 |
40+1/-3 |
240±20 |
<1.28 |
1A |
>1200 |
1 |
<300 |
|
42+1/-3 |
42+1/-3 |
240±20 |
<1.28 |
1A |
>1200 |
1 |
<300 |
||
|
44+1/-3 |
44+1/-3 |
240±20 |
<1.28 |
1A |
>1200 |
1 |
<300 |
||
|
8 |
FR207 |
52+1/-3 |
52+1/-3 |
240±20 |
<1.28 |
2A |
>1200 |
2 |
<300 |
|
55+1/-3 |
55+1/-3 |
240±20 |
<1.28 |
2A |
>1200 |
2 |
<300 |
||
|
58+1/-3 |
58+1/-3 |
240±20 |
<1.28 |
2A |
>1200 |
2 |
<300 |
||
|
9 |
FR307 |
80+1/-3 |
80+1/-3 |
240±20 |
<1.28 |
3A |
>1200 |
3 |
<300 |
|
90+1/-3 |
90+1/-3 |
240±20 |
<1.28 |
3A |
>1200 |
3 |
<300 |
||
High Efficieny Rectifier Chip
|
Number |
Model |
Size |
Electrical Parameters |
||||||
|
A(mil) |
B(mil) |
C(um) |
VF(V) |
IF(A) |
VR(V) |
IR(uA) |
TRR(ns)@ |
||
|
1 |
HER103 |
40+1/-3 |
40+1/-3 |
200±20 |
<0.98 |
1A |
>300 |
1 |
<50 |
|
42+1/-3 |
42+1/-3 |
200±20 |
<0.98 |
1A |
>300 |
1 |
<50 |
||
|
44+1/-3 |
44+1/-3 |
200±20 |
<0.98 |
1A |
>300 |
1 |
<50 |
||
|
2 |
HER203 |
52+1/-3 |
52+1/-3 |
200±20 |
<0.98 |
2A |
>300 |
2 |
<50 |
|
55+1/-3 |
55+1/-3 |
200±20 |
<0.98 |
2A |
>300 |
2 |
<50 |
||
|
58+1/-3 |
58+1/-3 |
200±20 |
<0.98 |
2A |
>300 |
2 |
<50 |
||
|
3 |
HER303 |
80+1/-3 |
80+1/-3 |
200±20 |
<0.98 |
3A |
>300 |
3 |
<50 |
|
90+1/-3 |
90+1/-3 |
200±20 |
<0.98 |
3A |
>300 |
3 |
<50 |
||
|
4 |
HER104 |
40+1/-3 |
40+1/-3 |
200±20 |
<1.0 |
1A |
>450 |
1 |
<50 |
|
42+1/-3 |
42+1/-3 |
200±20 |
<1.0 |
1A |
>450 |
1 |
<50 |
||
|
44+1/-3 |
44+1/-3 |
200±20 |
<1.0 |
1A |
>450 |
1 |
<50 |
||
|
5 |
HER204 |
52+1/-3 |
52+1/-3 |
200±20 |
<1.0 |
2A |
>450 |
2 |
<50 |
|
55+1/-3 |
55+1/-3 |
200±20 |
<1.0 |
2A |
>450 |
2 |
<50 |
||
|
58+1/-3 |
58+1/-3 |
200±20 |
<1.0 |
2A |
>450 |
2 |
<50 |
||
|
6 |
HER304 |
80+1/-3 |
80+1/-3 |
200±20 |
<1.0 |
3A |
>450 |
3 |
<50 |
|
90+1/-3 |
90+1/-3 |
200±20 |
<1.0 |
3A |
>450 |
3 |
<50 |
||
|
7 |
HER105 |
40+1/-3 |
40+1/-3 |
210±20 |
<1.25 |
1A |
>600 |
1 |
<50 |
|
42+1/-3 |
42+1/-3 |
210±20 |
<1.25 |
1A |
>600 |
1 |
<50 |
||
|
44+1/-3 |
44+1/-3 |
210±20 |
<1.25 |
1A |
>600 |
1 |
<50 |
||
|
8 |
HER205 |
52+1/-3 |
52+1/-3 |
210±20 |
<1.25 |
2A |
>600 |
2 |
<50 |
|
55+1/-3 |
55+1/-3 |
210±20 |
<1.25 |
2A |
>600 |
2 |
<50 |
||
|
58+1/-3 |
58+1/-3 |
210±20 |
<1.25 |
2A |
>600 |
2 |
<50 |
||
|
9 |
HER305 |
80+1/-3 |
80+1/-3 |
210±20 |
<1.25 |
3A |
>600 |
3 |
<50 |
|
90+1/-3 |
90+1/-3 |
210±20 |
<1.25 |
3A |
>600 |
3 |
<50 |
||
|
10 |
HER107 |
40+1/-3 |
40+1/-3 |
230±20 |
<1.68 |
1A |
>900 |
1 |
<70 |
|
42+1/-3 |
42+1/-3 |
230±20 |
<1.68 |
1A |
>900 |
1 |
<70 |
||
|
44+1/-3 |
44+1/-3 |
230±20 |
<1.68 |
1A |
>900 |
1 |
<70 |
||
|
11 |
HER207 |
52+1/-3 |
52+1/-3 |
230±20 |
<1.68 |
2A |
>900 |
2 |
<70 |
|
55+1/-3 |
55+1/-3 |
230±20 |
<1.68 |
2A |
>900 |
2 |
<70 |
||
|
58+1/-3 |
58+1/-3 |
230±20 |
<1.68 |
2A |
>900 |
2 |
<70 |
||
|
12 |
HER307 |
80+1/-3 |
80+1/-3 |
230±20 |
<1.68 |
3A |
>900 |
3 |
<70 |
|
90+1/-3 |
90+1/-3 |
230±20 |
<1.68 |
3A |
>900 |
3 |
<70 |
||
|
13 |
HER108 |
40+1/-3 |
40+1/-3 |
230±20 |
<1.68 |
1A |
>1100 |
1 |
<70 |
|
42+1/-3 |
42+1/-3 |
230±20 |
<1.68 |
1A |
>1100 |
1 |
<70 |
||
|
44+1/-3 |
44+1/-3 |
230±20 |
<1.68 |
1A |
>1100 |
1 |
<70 |
||
|
14 |
HER208 |
52+1/-3 |
52+1/-3 |
230±20 |
<1.68 |
2A |
>1100 |
2 |
<70 |
|
55+1/-3 |
55+1/-3 |
230±20 |
<1.68 |
2A |
>1100 |
2 |
<70 |
||
|
58+1/-3 |
58+1/-3 |
230±20 |
<1.68 |
2A |
>1100 |
2 |
<70 |
||
|
15 |
HER308 |
80+1/-3 |
80+1/-3 |
230±20 |
<1.68 |
3A |
>1100 |
3 |
<70 |
|
90+1/-3 |
90+1/-3 |
230±20 |
<1.68 |
3A |
>1100 |
3 |
<70 |
||
Super Fast Rectifier Chip
|
Number |
Model |
Size |
Electrical Parameters |
||||||
|
A(mil) |
B(mil) |
C(um) |
VF(V) |
IF(A) |
VR(V) |
IR(uA) |
TRR(ns)@ |
||
|
1 |
SF13 |
40+1/-3 |
40+1/-3 |
200±20 |
<0.95 |
1A |
>200 |
1 |
<35 |
|
42+1/-3 |
42+1/-3 |
200±20 |
<0.95 |
1A |
>200 |
1 |
<35 |
||
|
44+1/-3 |
44+1/-3 |
200±20 |
<0.95 |
1A |
>200 |
1 |
<35 |
||
|
2 |
SF23 |
52+1/-3 |
52+1/-3 |
200±20 |
<0.95 |
2A |
>200 |
2 |
<35 |
|
55+1/-3 |
55+1/-3 |
200±20 |
<0.95 |
2A |
>200 |
2 |
<35 |
||
|
58+1/-3 |
58+1/-3 |
200±20 |
<0.95 |
2A |
>200 |
2 |
<35 |
||
|
3 |
SF33 |
80+1/-3 |
80+1/-3 |
200±20 |
<0.95 |
3A |
>200 |
3 |
<35 |
|
90+1/-3 |
90+1/-3 |
200±20 |
<0.95 |
3A |
>200 |
3 |
<35 |
||
|
4 |
SF14 |
40+1/-3 |
40+1/-3 |
200±20 |
<0.95 |
1A |
>300 |
1 |
<35 |
|
42+1/-3 |
42+1/-3 |
200±20 |
<0.95 |
1A |
>300 |
1 |
<35 |
||
|
44+1/-3 |
44+1/-3 |
200±20 |
<0.95 |
1A |
>300 |
1 |
<35 |
||
|
5 |
SF24 |
52+1/-3 |
52+1/-3 |
200±20 |
<0.95 |
2A |
>300 |
2 |
<35 |
|
55+1/-3 |
55+1/-3 |
200±20 |
<0.95 |
2A |
>300 |
2 |
<35 |
||
|
58+1/-3 |
58+1/-3 |
200±20 |
<0.95 |
2A |
>300 |
2 |
<35 |
||
|
6 |
SF34 |
80+1/-3 |
80+1/-3 |
200±20 |
<0.95 |
3A |
>300 |
3 |
<35 |
|
90+1/-3 |
90+1/-3 |
200±20 |
<0.95 |
3A |
>300 |
3 |
<35 |
||
|
7 |
SF16 |
40+1/-3 |
40+1/-3 |
200±20 |
<1.25 |
1A |
>450 |
1 |
<35 |
|
42+1/-3 |
42+1/-3 |
200±20 |
<1.25 |
1A |
>450 |
1 |
<35 |
||
|
44+1/-3 |
44+1/-3 |
200±20 |
<1.25 |
1A |
>450 |
1 |
<35 |
||
|
8 |
SF26 |
52+1/-3 |
52+1/-3 |
200±20 |
<1.25 |
2A |
>450 |
2 |
<35 |
|
55+1/-3 |
55+1/-3 |
200±20 |
<1.25 |
2A |
>450 |
2 |
<35 |
||
|
58+1/-3 |
58+1/-3 |
200±20 |
<1.25 |
2A |
>450 |
2 |
<35 |
||
|
9 |
SF36 |
80+1/-3 |
80+1/-3 |
200±20 |
<1.25 |
3A |
>450 |
3 |
<35 |
|
90+1/-3 |
90+1/-3 |
200±20 |
<1.25 |
3A |
>450 |
3 |
<35 |
||
|
10 |
SF18 |
40+1/-3 |
40+1/-3 |
210±20 |
<1.68 |
1A |
>650 |
1 |
<35 |
|
42+1/-3 |
42+1/-3 |
210±20 |
<1.68 |
1A |
>650 |
1 |
<35 |
||
|
44+1/-3 |
44+1/-3 |
210±20 |
<1.68 |
1A |
>650 |
1 |
<35 |
||
|
11 |
SF28 |
52+1/-3 |
52+1/-3 |
210±20 |
<1.68 |
2A |
>650 |
2 |
<35 |
|
55+1/-3 |
55+1/-3 |
210±20 |
<1.68 |
2A |
>650 |
2 |
<35 |
||
|
58+1/-3 |
58+1/-3 |
210±20 |
<1.68 |
2A |
>650 |
2 |
<35 |
||
|
12 |
SF38 |
80+1/-3 |
80+1/-3 |
210±20 |
<1.68 |
3A |
>650 |
3 |
<35 |
|
90+1/-3 |
90+1/-3 |
210±20 |
<1.68 |
3A |
>650 |
3 |
<35 |
||
Ultra Fast Rectifier Chip
|
Number |
Model |
Size |
Electrical Parameters |
||||||
|
A(mil) |
B(mil) |
C(um) |
VF(V) |
IF(A) |
VR(V) |
IR(uA) |
TRR(ns)@ |
||
|
1 |
UF4003 |
42+1/-3 |
42+1/-3 |
200±20 |
<0.98 |
1A |
>200 |
1 |
<50 |
|
44+1/-3 |
44+1/-3 |
200±20 |
<0.98 |
1A |
>200 |
1 |
<50 |
||
|
46+1/-3 |
46+1/-3 |
200±20 |
<0.98 |
1A |
>200 |
1 |
<50 |
||
|
2 |
UF4004 |
42+1/-3 |
42+1/-3 |
200±20 |
<0.98 |
1A |
>450 |
1 |
<50 |
|
44+1/-3 |
44+1/-3 |
200±20 |
<0.98 |
1A |
>450 |
1 |
<50 |
||
|
46+1/-3 |
46+1/-3 |
200±20 |
<0.98 |
1A |
>450 |
1 |
<50 |
||
|
3 |
UF4007 |
42+1/-3 |
42+1/-3 |
220±20 |
<1.68 |
1A |
>1050 |
1 |
<70 |
|
44+1/-3 |
44+1/-3 |
220±20 |
<1.68 |
1A |
>1050 |
1 |
<70 |
||
|
46+1/-3 |
46+1/-3 |
220±20 |
<1.68 |
1A |
>1050 |
1 |
<70 |
||
